Type A2E200-AF02-51
Motor M2E068-CA
Phase 1~ 1~
Nominal voltage / VAC 230 230
Frequency / Hz 50 60
Method of obtaining data fa fa
Valid for approval/ standard CE CE
Speed (rpm) / min-1 2740 3120
Power consumption / W 50 61
Current draw / A 0.24 0.28
Capacitor / µF 1.5 1.5
Capacitor voltage / VDB 400 400
Max. back pressure / Pa 200 200
Min. ambient temperature / °C -25 -25
Max. ambient temperature / °C 75 75
Starting current / A 0.53 0.53
Mass 1.4 kg
Fan size 200 mm
Rotor surface Painted black
Blade material Sheet steel, painted black
Number of blades 5
Airflow direction «V»
Direction of rotation Counterclockwise, viewed toward rotor
Degree of protection IP44; installation- and position-dependent
Insulation class «B»
Moisture (F) / Environmental (H)
protection class H1
Installation position Shaft horizontal or rotor on bottom; rotor
on top on request
Condensation drainage holes On rotor side
Mode S1
Motor bearing Ball bearing
Touch current according to IEC
60990 (measuring circuit Fig. 4, TN
system) < 0.75 mA
Motor protection Thermal overload protector (TOP)
internally connected
with cable Variable
Protection class I (with customer connection of protective
earth)
Conformity with standards
EN 60335-1; CE
Approval UL 507; CCC; EAC
