EC crossflow fans, made of stable extruded aluminium
profile. Side plates made of galvanised steel. Air flows of EC crossflow fans up to 2100 m³/h and static pressure increases of up to 120
Pa can be achieved. Air flows of AC crossflow fans up to 3050 m³/h
and static pressure increases of up to 375 Pa can be achieved.
Characteristics and special features
– Crossflow fans are characterised by high air flows at low pressures
– The high number of blades results in very good sound characteristics with very little tonal noise of blades
– Medium temperature from -20°C to 70°C
– Motor ambient temperature from -20°C to 40°C
– Motor attachment as standard on the right; available on the left
on request
– Balance quality G6.3
Motor concepts
External rotor motors
– ECblue EC technology with integrated controller matched to the
fan
– AC technology
Type QK10A-2DM.38.FE
Article number 106874
Max. speed 2500Rpm
Electrical power max. 450W
Maximum absorbed current 230V 1,48A 400V 0,85A
IP10 protection
Mass 7Kg
According ErP 2015
