Type 3314 NN
Nominal voltage VDC 24
Nominal voltage range VDC 18 .. 28
Speed (rpm) min-1 2650
Power consumption W 1.8
Min. ambient temperature °C -20
Max. ambient temperature °C 75
Air flow m3/h 80
Sound power level B 4.7
Sound pressure level dB(A) 35
Housing material Glass-fiber reinforced PBT plastic
Impeller material Glass-fiber reinforced PA plastic
Mass 0.19 kg
Dimensions 92 x 92 x 32 mm
Airflow direction Exhaust over struts
Direction of rotation Clockwise, viewed toward rotor
Degree of protection IP40
Storage Ball bearing
Service life L10 at 40 °C 65000 h
Service life L10 at maximum
temperature 27500 h
Cable With leads AWG 24 UL 1061, TR 64
COMPACT AXIAL FANS DC
