Helicocentrifugal fans of low
profile.
The motor body can be dismantled without
need to touch the ducts.
Manufactured in plastic material (models
160 to 800) or in sheet steel
galvanised and protected with paint
anti-corrosive epoxy-polyester (models 1000 a 6000).
Engines
Models 160 to 2000:
IP44, Class B, with ball bearings
permanent lubrication and protective
thermal.
Supply voltage:
Single-phase 230V-50Hz
(models 160 to 350)
Single-phase 230V-50/60Hz
(models 500 to 2000)
2 or 3 speed motors, also
adjustable by voltage variation.
Models 4000 to 6000:
IP54, Class F, with ball bearings
permanent lubrication and protective thermal.
Supply voltage:
Single-phase 230V-50/60Hz
Three-phase 400V-50/60Hz
(model 4000) or 400V-50Hz (model 6000)
Adjustable by voltage variation.
Other information
The three-phase models are adjustable
by means of a frequency converter.
Models TD-MIXVENT-T
They incorporate a timer that can be adjusted between
1 and 30 minutes.
They have 1 or 3 speed motor,
depending on model, not adjustable.
TD-MIXVENT TD-500/160 3V
Speed (r.p.m.) 2590 / 2150 / 1820
Maximum power consumption (W) 53 / 44 / 41
Maximum absorbed current (A) 0.21 / 0.19 / 0.18
Flow rate at free discharge (m3/h) 560 / 470 / 390
Sound pressure level* (dB(A)) 35 / 31 / 26
Working temperature (°C) -20/+60
Weight (kg) 2,7
Duct Ø (mm) 160
Optional 3-speed switch COM-3 INTER 4P
Optional voltage regulator RMB-1,5 REB-1.
